Big Cyclone Fast Automatic Color Change
A:Working Principle of Large Cyclone Secondary Recycling Spray Booth:
The powder sprayed from the spray gun, the part which is not adhesion on the workpiece is brought to the inside of the large cyclone by the airflow that generated by the exhaust fan, the larger powder is be separated in the separator and drop on the vibrating screen, shake the sieve through the vibration motor, then the powder which has been removed impurities is dropped into the powder recovery group. Return to the powder box through the powder recovery pump and the powder supplying tube, then be reused . Effectively reduces the waste of powder.
The powder that has not been separated from the large cyclone is sucked into the secondary recovery, the filter element in the secondary recovery separates the remaining powder from the air, then the purified air is discharged to the inside of the workshop.
The filter element will be cleaned with compressed air for a period of time via the rotate wing and the powder will be blown into the powder collecting bucket.
B:Large cyclone recovery system:
The filter powder recovery system has the outstanding advantages of easy color change, high recovery efficiency, small space and simple installation. Large cyclone and filter secondary recovery system, the powder recovery rate can reach more than 99.2%. The powder falling into the bottom in a small cyclone and separated into a powder bucket, then sent to a powder supply cylinder for recycling. The filter element is provided with a continuously adjustable pulse back flushing device. The compressed air is continuously blown from the inside to the outside according to the set pulse interval and pu.
